Rotary Drum Conveyor and Filter Manufacturers in India

Name: Rotary Drum Conveyor
Brand: Unique Products

Handles floating aluminium, cast iron, brass and steel chips with 100-500 micron filtration - and zero filter media consumables.

Unique Products · Hubballi

Rotary drum conveyor with stainless steel filtration drum by Unique Products India

Aluminium machining Cast iron fines Brass machining Media-free filtration Centralized systems

Get a Quote WhatsApp Enquiry

Overview

When handling chips of aluminium, cast iron, brass and steel, the fines tend to float with the coolant and are difficult to filter. The rotary drum conveyor gives excellent results in exactly this situation.

It is essentially a scraper conveyor equipped with a stainless steel drum, continuously driven by the conveyor chain itself. Fine chips are retained on the drum periphery and are back-washed with nozzles fed by a pump discharge, which clears the clogged chips as the drum rotates. The clean liquid flows into the clean tank area.

Because expensive filter media are avoided entirely, there are no consumables. A filtering accuracy of 100 to 500 microns is achieved. The effective filtration significantly reduces the frequency of cleaning tanks and machine downtime. Combined with slat type conveyors and multiple drums for higher flow rates, it gives a wide choice of application.

Key Features

Handles floating fines - aluminium, cast iron, brass, steel
Stainless steel drum driven by the conveyor chain itself
Automatic back-wash nozzles clear the drum as it rotates
No filter media - zero consumable cost
Filtering accuracy 100 to 500 microns
Reduces tank cleaning frequency and machine downtime
Multiple drums for higher flow rates

Technical Overview
Filtering accuracy	100 - 500 microns
Drum	Stainless steel, chain driven
Cleaning	Automatic nozzle back-wash from pump discharge
Consumables	None - no filter media required
Chip types	Aluminium · Cast iron · Brass · Steel
Scaling	Combine with slat conveyors and multiple drums
