View detailsConveyorised Tunnel Type Washing Machine
Continuous through-feed washing, drying and oiling for high volumes - multistage tunnels with belts 200-1500 mm wide.
High-volume component washing Pre-assembly cleaning Post-machining degreasing Wash-dry-oil lines
Overview
The conveyorised tunnel washing machine delivers effective washing, drying and oiling for a wide variety of components. Because it is a continuous, through-feed machine it handles large volumes with easy operation and real savings in manpower.
Components are placed directly on the conveyor belt - manually, or by hoist for heavy parts. As the belt moves continuously through the tunnel, high-pressure jets on the top, sides and bottom clean every surface. Belt speed is settable for best washing results.
The belt itself is robustly designed in honeycomb or chain construction with carbon steel or stainless steel fitments, in widths from 200 mm to 1500 mm or as requested. Machines can be built in multistage design offering pre-wash, final wash, drying and oiling in one pass. An inline filter keeps the wash liquid clean and prevents nozzle clogging, while an oil skimmer removes oil scum to extend media life.
Key Features
- Continuous through-feed - high volume, low manpower
- Multistage: pre-wash, final wash, drying, oiling
- High-pressure jets on top, sides and bottom
- Honeycomb or chain belt, CS or SS fitments
- Settable belt speed for best results
- Inline filter prevents nozzle clogging
- Oil skimmer extends wash-media life
- Hot-air blower removes excess media
| Belt width | 200 mm - 1500 mm (or as requested) |
|---|---|
| Belt type | Honeycomb · Chain, with CS or SS fitments |
| Stages | Pre-wash → Final wash → Drying → Oiling (multistage build) |
| Cleaning | High-pressure jets top, side & bottom |
| Filtration | Inline filter + oil skimmer |
| Drying | Hot-air blower |
